RSV-UFDC Underfloor Single Duct VAV Terminals

Royal Service Group, founded in 1975, a multinational company, a leader in HVAC industry, providing world-class products and services, equipped with one AHRI standards laboratory, one VAV training center, 4 production bases, 30+ practical patents, 46 years international engineering experience with thousands upon thousands of excellent projects allover the world.

HVAC Air System Air-Conditioning Global Leader and Partner
International Manufacturer of VAV Terminal Unit Box
AHRI•UL•ETL CERTIFICATED•30+ UTILITY MODEL PATENTS

INTERNATIONAL MANUFACTURER OF AIR-CONDITIONING VAV TERMINALS
Product by Royal Service Air-Conditioning
NAME: Underfloor Cooling or Heating Only VAV Linear Diffusers
MODEL: RS Uderfloor Terminal SERIES-UFDC

Underfloor Air Distribution Systems (UFAD) are rapidly penetrated the office building arena across the world because they provide a number of advantages, (and a few disadvantages) over conventional office building HVAC systems. This brochure will present current and new design approaches and new solutions that refine and improve the performance and flexibility of (UFAD) systems. Included in this brochure are explanations of maintenance of uniform supply temperatures in the underfloor plenum, introduction of thermal stratification in the occupied spaces, product and design applications of leakage issues in the floor plenum, control of space humidity for humid climates.

The Green Building Council supports underfloor design and applications for improved indoor air quality and reduced energy.

Under-Floor Air Distribution (VAV / UFAD), compared with the ceiling air supply system
Air conditioned at (IP 60 F to 65 F, Sl 16-18 C) supplied directly from a central located floor air handler unit to the under floor and as a plenum air is distributes up throughout floor and diffused in a swirling air mixing distribution action. Channeling supply air under the floor is accomplished with zone units and pressure modulation controlled dampers for variable a distribution. UFAD have excellent zoning of large spaces at different air and temperature conditions with standard underfloor diffusers. Supply air swirl motion mixes and increases the comfort and IAQ levels. Ceiling systems blow air down and can not mix properly low air flow.

Underfloor air supply systems include, but are not limited to the following advantages.
♦ Reduce building construction costs
♦ Reduce direct cost of initial installation and reduce operating costs
♦ Energy saving are direct from less of a heating load to operate UFAD
♦ Excellent airflow patterns
♦ Forgiving tenant improvement system flexibility
♦ LEED points and “Green Design”, to create a comfortable environment

Under-floor air supply systems Applications
Under-floor air supply systems applications are suitable for office buildings. with an open floor office layout each diffusers can allow the occupant po adjust the air supply terminal according to individual needs, and to meet single zones that need independent control and environmental control.

RSV-UFDC Cooling or Heating Only VAV Linear Floor Diffusers
RSV UFD series VAV linear underfioor diffusers are designed for application in raised access floor air distribution systems High quality. heavy duty, extruded aluminum linear grilles are featured providing an architecturally appealing face RSV UFD series provides variable air volume cooling or heating control for ducted or non-ducted applications. A 90 rotation low leakage damper and integral modulating actuator provide precise airflow control.

♦ Designed for use in raised floor air distribution systems.
♦ Suitable for ducted or non-ducted applications.
♦ Pressure dependent airflow control mode.
♦ Designed for different system application.
♦ High quality, heavy duty, extruded aluminum linear grilles and low leakage air damper.

UNDERFLOOR Terminal • Wide Applications
Applications
♦ UNDERFLOOR APPLICATIONS
♦ RAISED FLOOR AIR DISTRIBUTION SYSTEMS
♦ SUITABLE FOR OFFICE BUILDING, etc..

RSV-UFDC Features:
Cooling or Heating Only VAV Linear Floor Diffusers
♦ Designed for use in raised floor air distribution systems.
♦ Suitable for ducted or non-ducted applications.
♦ Pressure dependent airflow control mode.
♦ Designed for different system application.
♦ High quality, heavy duty, extruded aluminum linear grilles and low leakage air damper.
